WOODWARD 5463-316 is a digital input/output (I/O) module designed for industrial control systems and manufactured by Woodward.
1. Product Overview
Product Type: Digital I/O Module
Application Range: Primarily used in steam turbine control systems, generators, compressors, and other industrial automation control applications.
Core Functions:
The module typically provides high-speed digital input and output capabilities, allowing it to monitor machine status, receive sensor signals, and control actuators.
It is compatible with various Woodward Digital Microprocessor (DMP) series controllers (such as 9907-149 and 9907-162), serving as a communication interface between field devices and the control system.
2. Technical Specifications
Although detailed public specifications are limited, based on similar models in the same series (such as 5466-316), the module is expected to have the following basic characteristics:
Electrical Characteristics:
-
Input/Output Voltage: Typically supports 24 VDC or 120/240 VAC
-
Current/Power: Low power consumption design suitable for centralized control systems
Operating Environment:
-
Temperature Range: -40°C to +85°C (industrial standard range)
-
Protection: Designed with protective features suitable for complex industrial environments
3. Key Applications
Steam Turbine Control:
Used as a digital signal acquisition module to monitor key parameters such as speed and temperature.
Generator Sets:
Receives signals from external sensors and transmits them to the main controller.
System Integration:
Functions as part of a modular control system, enabling easier system expansion, upgrades, and maintenance.
